ISO 7380-2 defines the specifications and performance requirements for hexagon socket button head flange screws. These screws are widely used in industrial manufacturing, automotive, mechanical, and electronic fields due to their unique design and reliable performance. This article provides a detailed introduction to the usage and application scenarios of ISO 7380-2 screws.
Usage of ISO 7380-2 Hexagon Socket Button Head Flange Screws
1. Tool Selection
The head of ISO 7380-2 screws features a hexagon socket, requiring a hex key or power tool for installation. Select a tool size that matches the hex socket of the screw head to avoid damaging the head during installation.
2. Preparation Before Installation
Before installing ISO 7380-2 screws, ensure the precision of the threaded hole. Since the screw has a flange (washer face), the installation hole should be a straight hole without a countersink. If the screw head needs to be flush with the installation surface, a washer can be used for adjustment.
3. Installation Steps
Align the screw with the hole, ensuring it is perpendicular to the installation surface.
Insert the hex key or power tool gently into the hex socket of the screw head and rotate evenly until the screw is fully tightened.
If using a power tool, pay attention to controlling the tightening torque to avoid damaging the screw or the installed component due to excessive tightening.
4. Notes for Attention
Keep the tool perpendicular to the screw head during installation to prevent slipping or damage to the head.
For applications requiring repeated disassembly, consider using high-strength and corrosion-resistant materials, such as stainless steel.
Regularly inspect installed screws to ensure they have not loosened due to vibration or other external forces.
Application Scenarios of ISO 7380-2 Hexagon Socket Button Head Flange Screws
1. Industrial Manufacturing
ISO 7380-2 screws are widely used in industrial manufacturing to secure various mechanical components, such as motor housings and sensors. Their high strength and wear resistance meet the demands of industrial environments.
2. Automotive Manufacturing
In the automotive industry, ISO 7380-2 screws are commonly used to fasten internal vehicle components, especially in areas requiring vibration resistance and high-temperature tolerance. The flange design provides sufficient clamping force while maintaining a neat appearance.
3. Electronic Communication Equipment
In electronic communication devices, ISO 7380-2 screws are used to secure PCB boards and electronic component housings. The button head design allows for a flat surface, enhancing aesthetics.
4. Medical Devices
In medical devices, ISO 7380-2 screws are used to fasten the housings and internal components of precision instruments. The button head design and hex socket structure provide higher installation precision and stability, meeting the requirements for aesthetics and cleanliness in medical equipment.
5. Construction and Furniture Industry
In construction and furniture manufacturing, ISO 7380-2 screws are used to fix components such as door frames, window frames, and drawer slides. The flange design allows for a flat surface, enhancing aesthetics. Additionally, stainless steel screws offer good corrosion resistance, making them suitable for damp environments.
6. Food Machinery
In food machinery, ISO 7380-2 screws are used to secure equipment housings and internal components. The stainless steel material and flange design meet the requirements for hygiene and durability in food processing equipment.
Technical Specifications of ISO 7380-2 Hexagon Socket Button Head Flange Screws
Materials: ISO 7380-2 screws are available in materials such as carbon steel, stainless steel (e.g., A2-70, A4-70). Stainless steel is particularly suitable for applications requiring high corrosion resistance.
Strength Grades: Common strength grades include 8.8, 10.9, and 12.9.
Surface Treatments: Screws can be finished with no treatment, electroplating, zinc-nickel alloy coating, etc.
Size Range: The diameter range of the screws is from M3 to M16, with lengths customized according to specific requirements.
Conclusion
With their unique design, high strength, and corrosion resistance, ISO 7380-2 hexagon socket button head flange screws have become ideal fasteners for multiple fields, including industrial manufacturing, automotive, electronic communication, medical devices, construction, and food machinery. By mastering the correct installation methods and selecting appropriate materials, their performance advantages can be fully utilized to meet the demands of various complex working conditions. As industrial technology continues to evolve, the application scope of ISO 7380-2 screws will further expand, providing more reliable fastening solutions for modern manufacturing.
